Promise Technology Pegasus32 R4 72TB RAID Storage - 4-Bay Thunderbolt 3/USB 3.2
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
Promise Technology Pegasus32 R4 72TB RAID Storage - 4-Bay Thunderbo...
Designed for creative professionals, the Pegasus32 R4 72TB 4-Bay Thunderbolt 3 RAID Array from Promise Technology delivers the speed, capacity, and protection needed for large projects and backups. Featuring four drive bays equipped with hot-swappable 18TB 7200 rpm SATA III 3.5in hard drives, the 72TB array has a maximum data throughput of 2800 MB/s. Its hardware-based controller supports RAID 0, 1, 1E, 5, 6, and 10 configurations, and the fan-cooled drives are pre-configured for RAID 5. Connectivity to your host system is established using a 40 Gb/s Thunderbolt 3 port that also provides up to 85W of charging power, while a second Thunderbolt 3 port may be used for daisy chaining and supports up to 15W of charging power. If your system doesn't support Thunderbolt 3, both ports are backward compatible with 10 Gb/s USB 3.2 Gen 2. There is also a DisplayPort 1.4 connector that supports 8K displays for large and highly detailed projects. The drives come pre-formatted for macOS 10.14 or later, but may be reformatted for Windows 10.
Thunderbolt 3
Thunderbolt 3 is a hardware interface that utilizes the reversible USB-C connector. Doubling the speed of its predecessor, Thunderbolt 3 features a maximum throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB 3.2 Gen 2 (3.1 Gen 2/3.1) at up to 10 Gb/s, and dual-bandwidth DisplayPort 1.2 allows you to connect up to two 4K displays simultaneously. Additionally, you can daisy chain up to six devices from a single Thunderbolt 3 port.
USB 3.2 Gen 2
Doubling the speed of its predecessor, USB 3.2 Gen 2 features a maximum throughput of 10 Gb/s when used with compatible devices.
ChronoSync
The Pegasus32 RAID array comes bundled with ChronoSync Pegasus Edition, which allows you to back up your data, clone hard drives, sync files between devices, and offers redundant cloud storage.
Main
| Capacity | 72 TB |
| Bays | 4 |
| Raid | RAID 0 |
| Drive Speed/Type | 7200 rpm |
| Configuration | Core |
| Color | Black/Black |
Key Features
| 72TB total storage with 4 × 18TB SATA III 3.5" HDDs (7200 RPM) | |
| Preconfigured in RAID 5, supports RAID 0/1/5/6/10/JBOD | |
| Transfer speeds up to 2800 MB/s | |
| 4 × hot-swappable 3.5" SATA III drive bays | |
| Dual Thunderbolt 3 ports (40 Gb/s) and DisplayPort 1.4 | |
| PMC Sierra 8067 processor with 1 GB DDR3 memory | |
| Compatible with macOS 10.14 or later and Windows 10 | |
| Efficient cooling with 92 mm fan | |
| Certified for BIS, BSMI, CE, FCC, RCM, TUV, VCCI, cTUVus |
Storage
| Total Capacity | 72 TB |
| Included Drives | 4 × 18TB SATA III 3.5" HDDs (7200 RPM) |
| RAID Support | 0, 1, 5, 6, 10, JBOD |
| Transfer Rate | Up to 2800 MB/s |
| Drive Bays | 4 × 3.5" SATA III (Hot-Swap) |
Connectivity
| Ports | • 2 × USB-C Thunderbolt 3 (40 Gb/s) • 1 × DisplayPort 1.4 |
Computing
| Processor | PMC Sierra 8067 |
| Memory | 1 GB DDR3 @ 1866 MT/s |
Compatibility
| OS Compatibility | macOS 10.14 or later, Windows 10 |
| Installed OS | None |
| Mobile App | Not supported |
Networking
| Link Aggregation | No |
| iSCSI Support | No |
Power & Cooling
| Input Power | 100–230 VAC, 50/60 Hz |
| Power Supply | 1 × 250 W |
| Cooling | 1 × 92 mm Fan |
Physical & Environmental
| Dimensions | 9.8 × 7.7 × 7.4 in / 248.9 × 195.6 × 188 mm |
| Weight | 15.0 lb / 6.8 kg (with drives) |
| Operating Temp | 41–95°F / 5–35°C, 10–95% humidity |
| Storage Temp | -40–158°F / -40–70°C, 5–95% humidity |
| Certifications | BIS, BSMI, CE, FCC, RCM, TUV, VCCI, cTUVus |
