Xenarc Technologies was the first to market and manufacture the iconic 700 series line of small touchscreen solutions, and it followed up the success of that line with the affordable 705 series 7-inch touchscreen that utilizes an LED backlight system. The result is a 7-inch monitor with less power consumption and a thinner profile, yet all the bells and whistles customers expect from a 7-inch touchscreen.
4-Wire Resistive Touchscreen Panel
This affordable yet versatile 7-inch small touchscreen video display monitor incorporates a 4-wire resistive touchscreen panel. Use the convenient touch-screen as your input device, control your mouse cursor or the mini onscreen keyboard that comes with your operating system. This heavy-duty, rugged display utilizes the USB port as the interface. You can connect several 705TSV displays to your computer and they’ll work simultaneously through the multi-monitor display support. Xenarc Technologies manufactures the most heavy-duty, rugged touchscreen small monitor displays.
Connectivity
| External Ports | USB Type-C |
General
| AC Input Power | DC 12V |
Environmental
| Storage Temperature | -30°C to 80°C |
| Operating Temperature | -4 to 158-degree F (-20 to 70-degree C) |
Physical
| Weight | 1.12 lb |
| Wall Mounting | Not Available |
Display
| Resolution | 800 x 480 |
| Brightness | 500 cd/m² |
| TV Screen Size (Diagonal) | 7" |
| Variable Frame Rates | Not Available |
| Touch Screen | 42190 |
| Viewing Angle (H x V) | 140 x 120° |
| Contrast Ratio | 500:1 |
| Dot Pitch | 1,152,000 (dots) |
Xenarc Technologies 7-Inch Touchscreen with VGA and AV Inputs
| Screen size | 7 inch, diagonal (16:9) |
| Physical resolution | 800 (H) x 480 (V), WVGA |
| Supported resolution | 640 x 480 to 1280 x 1024 |
| Dot resolution | 2400 x 480 = 1,152,000 (dots) |
| LCD brightness | 500 cd/m² |
| Contrast ratio | 400:1 |
| Viewing angle | 140 degree horizontal, 120 degree vertical |
| Response time (Tr/Tf) | 10/15ms (typical) |
| Touch screen interface | USB port |
| Operating voltage range | 9 to 30 VDC |
| Power supply | 12 VDC |
| Power consumption | <5 W |
| Operating temperature | -4 to 158-degree-F (-20 to 70-degree-C) |
| Storage temperature | -22 to 176-degree-F (-30 to 80-degree-C) |
| MTBF (Mean Time Between Failures) | >55,000 hours or >6.2 years of continuous operation |
| Dimensions (W x H x D) | 193.97 x 123.97 x 30.5 mm |
| Weight | 1.12 lb |
