Expanding its small form factor display product line into previously uncharted territories, Xenarc Technologies presents the first in its class 7-inch direct sunlight readable, IP65 dust/splash proof, capacitive touchscreen small monitor with the built-in waterproof speaker. The 1,000NIT brightness of this water and dust-resistant 7-inch small monitor makes it ideal for tough outdoor applications under direct sunlight, and also protects from environmental hazards from harsh industrial areas with its IP65 certified casing.
Features
The 7-inch HDMI small monitor offers all of the innovation and inputs as the 700 series models along with a 7-inch capacitive touchscreen panel. Capacitive sensing provides a more responsive touch interface than resistive touch. It achieves this by using the capacitance of human skin to detect the proximity or position of the input. Proximity sensing allows the touch interaction to work even if protective glass or coating is used over the touch display.
IP65 Water-Resistant
The IP65 rating on the 7-inch small monitor display provides for protection against solid objects and liquids. This monitor is guaranteed to prevent any amount of dust from entering the device, making it completely dustproof. Further, it is guaranteed to protect from water projected from a nozzle from having any harmful effect.
Applications
By utilizing high-grade industrial components, this 7-inch Industrial Display HDMI, VGA, DVI Video small monitor is perfect for industrial, in-car computing applications or any other applications where a small, durable, environmentally rugged display is required.
General
| AC Input Power | DC 12V |
Environmental
| Storage Temperature | -30°C to 80°C |
| Operating Temperature | -4 to 158-degree F (-20-degree C to 70-degree C) |
Physical
| Weight | 2.64 |
| Wall Mounting | Not Available |
Video
| Video System | NTSC |
Display
| Resolution | 1920 x 1080 |
| Brightness | 1000 cd/m² |
| TV Screen Size (Diagonal) | 7" |
| Variable Frame Rates | Not Available |
| Contrast Ratio | 700:1 |
| Dot Pitch | 1,843,200 (dots) |
Xenarc Technologies 7-inch IP65 LCD Touchscreen LCD Monitor with VGA, HDMI, DVI Inputs
| Screen size | Diagonal 7-inch (16:9) |
| Physical resolution | 1024 (H) x 600 (V) WXGA |
| Supported resolution | 640 x 480 to 1920 x 1080 |
| Dot resolution | 3072 x 600 = 1,843,200 (dots) |
| Brightness | 1000 cd/m² |
| Contrast ratio | 700:1 |
| Viewing angle | 150-degree horizontal, 145-degree vertical |
| Response time (Tr/Tf) | 10/15ms (Typ.) |
| Touch screen interface | USB port |
| Operating voltage range | DC 10V to 35V |
| Power supply | DC 12V |
| Power consumption | ≤ 20W |
| Operating temperature | -4 to 158-degree F (-20 to 70-degree C) |
| Storage temperature | -22 to 176-degree F (-30 to 80-degree C) |
| MTBF (Mean time between failures) | > 55,000 Hours or > 6.2 Years of continuous operation |
| Dimension (mm) | 205.2W x 139.5H x 28.7D |
| Weight | 2.64 lb |
