The AGM ObservIR LRF Thermal and Digital Day and Night Binocular in Black has some of the most technologically advanced and feature-packed optics in the world. The primary engine behind these binocular lies within the main thermal viewing channel, with its high-sensitivity 12-micron detector. Unlike other thermal binoculars on the market, the ObservIR LRF also come outfitted with a digital day and night channel as well, which is great for aiding in recognition of targets detected by the thermal channel. The built-in 1000m laser rangefinder simply takes the ObservIR LRF to another level, and this is without even mentioning its 64GB of internal memory and Wi-Fi compatibility. The ObservIR LRF monoculars also come packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: high-sensitivity thermal detector, 60mm objective lens with a 1.0 aperture, 3840x2160 ultra-low light CMOS sensor, various viewing modes, multiple color palettes, picture-in-picture mode, built-in laser rangefinder, GPS module, long-range IR illuminator, up to 8 hours of battery life on removable, rechargeable 18650 batteries, USB Type-C port for external power capabilities, and IP67 waterproof certification. The package includes four 18650 batteries, wrist strap and charger.
Features
| Water-Resistant | Yes |
General
| Weight | 1.97 lb |
Night Vision
| Resolution | 1280 x 1024 |
| Infrared Illuminator | Yes, Built-In |
Performance
| Magnification | 2.5x |
| Objective Lens Diameter | 60mm |
| Minimum Focus Distance | Up to 1000 meter |
| Diopter Adjustment Correction | -5 to +3 |
AGM ObservIR LRF Thermal and Digital Binocular with 12-Micron Sensor and IR Illuminator
| Interpupillary Distance | 60 mm to 74 mm |
| Safety Class for Laser | Class 1 |
| Palettes | Black hot, white hot, red hot, fusion |
| Dimensions | 9.1 x 6.0 x 3.3-inch (230 x 153 x 83 mm) |
| Infrared Illuminator | Built-in 850nm Smart IR. Power and beam angle adjustment |
| Distance Measurement | Laser rangefinder up to 1000 m, plus-minus 1 m accuracy |
| Scene Mode | Jungle, recognition |
| Video Recording | Yes |
| Audio Recording | Yes |
| Magnification | Thermal channel - 2.5x - 20x, optical channel - 5.5x - 22x |
| Detector Type | Thermal detector - 12 micrometer VOx uncooled focal plane array, digital sensor - 3840 x 2160, 1/88-inch progressive scan CMOS |
| FFC (Flat Field Correction) | Auto, manual, external correction |
| Highest Temperature Spot Tracking | Yes |
| Standby Mode | Yes |
| Refresh Rate | 25 Hz |
| Resolution | 1280 × 1024 |
| Laser Wavelength | 905 nm |
| Detection Range (6 Feet object) | 3100 m |
| Snapshot | Yes |
| Lens System | Thermal channel - 60 mm, F1.0 / optical channel - 60 mm, F2.2 |
| NETD | Less than 18 mK (77-degree F, F equals 1.0) |
| Field of view (H x X) | Thermal channel - 14.6 x 8.8, optical channel - 6.9 x 4.1-degree |
| Diopter Adjustment Range | Minus 5 to plus 3 |
| Monitor | 1920 x 1080, 0.49 inch, OLED, 50 FPS |
| Display | Day, night, auto |
| Storage | 64 GB EMMC |
| Battery Type | Replaceable and rechargeable Li-ion battery pack |
| Wi-Fi | Yes |
| Battery Life (Operating) | 7.5 hours |
| Power supply | 5 VDC/2 A, USB Type-C interface (Supports external power supply) |
| Operating Temperature Range | Minus 4 to 131-degree F (minus 20 to 55-degree C) |
| Weight | 1.97 lb (0.89 kg) |
| Protection Level | IP67 (waterproof) |
