- Blackmagic Design UltraStudio Express Recorder 3G Video Capture Device
Blackmagic Design UltraStudio Express Recorder 3G Video Capture Device
- Captures SD and HD video through 3G-SDI or HDMI
- Supports video standards up to 1080p60
- Provides 10-bit broadcast-quality video connections
- Connects through USB Type-C with USB 40Gbps support
- Works with compatible USB4 and Thunderbolt 4 computers
- Supports Mac, Windows, and Linux systems
- Handles up to 16 embedded SDI audio channels
- Handles up to 8 embedded HDMI audio channels
Bring a professional camera, deck, and video sources into your production computer with the Blackmagic Design UltraStudio Express Recorder 3G. This compact input-only video capture device accepts SD and HD signals via 3G-SDI or HDMI, making it a practical choice for live streaming, editing, content archiving, and supported image-processing workflows.
Capture SD and HD Video up to 1080p60
The UltraStudio Express Recorder 3G supports common SD and HD video standards up to 1080p60. Its switchable SDI input handles 270 Mb, 1.5G, and 3G rates, while the HDMI 2.0 Type A input accepts standard definition and high definition sources. Broadcast quality video connections support compressed and uncompressed formats for flexible acquisition workflows.
Fast USB4 Computer Connectivity
A USB Type C interface supports USB 40Gbps signaling for connection to compatible USB4 or Thunderbolt 4 computers. The device receives power through the same Type C connection, helping reduce cable clutter during desktop, studio, and portable production. Supported operating systems include Mac, Windows, and Linux.
Production Software and Embedded Audio Support
The recorder works with supported applications including DaVinci Resolve, OBS, vMix, Wirecast, Zoom, and other capture software. Embedded audio support provides up to 16 channels through SDI and 8 channels through HDMI. Media Express, Blackmagic Desktop Video Utility, and Blackmagic drivers support setup, capture, and device management. HDMI input cannot capture copy-protected sources.
SDI Connections
| SDI Video Inputs | 1 x 10 Bit SD and HD Switchable |
| SDI Rates | 270 Mb, 1.5G, 3G |
| SDI Audio Inputs | 16 Embedded Channels in SD and HD |
| SDI Video Sampling | 4:2:2 and 4:4:4 |
| SDI Audio Sampling | 48 kHz, 24 Bit |
| SDI Color Space | Rec 601, Rec 709, and Rec 2020 |
| SDI Metadata Support | RP 188, SMPTE 12M-2, and Closed Captioning |
| SDI Compliance | SMPTE 259M, SMPTE 274M, SMPTE 296M, SMPTE 424M, and SMPTE 425M Level A and Level B |
HDMI Connections
| HDMI Video Inputs | 1 x HDMI 2.0 Type A Connector |
| HDMI Audio Inputs | 8 Embedded Channels in SD and HD |
| HDMI Video Sampling | 4:2:2 and 4:4:4 |
| HDMI Audio Sampling | 48 kHz, 24 Bit |
| HDMI Color Space | Rec 601, Rec 709, and Rec 2020 |
| HDMI Color Configuration | HDMI 2.0 Supports Deep Color |
| Copy Protection | Cannot Capture Copy Protected HDMI Sources |
Computer Interface
| Interface | 1 x USB Type C Supporting USB 40Gbps |
| Required Connection | USB Type C Port with 40Gbps Signaling Rate |
| Compatible Computer Connections | USB4 or Thunderbolt 4 |
| Power | Powered Through the USB Type C Cable |
Supported SD Video Standards
| 525i59.94 NTSC | |
| 625i50 PAL |
Supported HD Video Standards
| 720p50, 720p59.94, and 720p60 | |
| 1080i50, 1080i59.94, and 1080i60 | |
| 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, and 1080PsF30 through SDI | |
| 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, and 1080p60 |
Supported 2K SDI Standards
| 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, and 2KPsF30 DCI | |
| 2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp50 DCI, 2Kp59.94 DCI, and 2Kp60 DCI |
Color Precision
| SDI | 8, 10, and 12 Bit RGB 4:4:4 up to 1080p30 |
| SDI | 8 and 10 Bit YUV 4:2:2 in All Standards |
| HDMI | 8 Bit RGB 4:4:4 in All Standards |
| HDMI | 8 Bit YUV 4:4:4 in All Standards |
| HDMI | 12 Bit YUV 4:2:2 in All Standards |
Hardware Frame Buffer
| v210 | 10 Bit YUV |
| 2vuy | 8 Bit YUV |
| ARGB and BGRA | 8 Bit RGB |
| r210 | 10 Bit RGB |
| R12B and R12L | 12 Bit RGB |
Supported Codecs
| AVC Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV NTSC, DV PAL, DVCPRO50, DVCPROHD, DPX, HDV, and HEVC | |
| XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR, and DNxHD | |
| Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, and Apple ProRes 422 Proxy | |
| Uncompressed 8 Bit 4 | 2:2, Uncompressed 10 Bit 4:2:2, and Uncompressed 10 Bit 4:4:4 |
Included Software Support
| Mac and Windows | Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility, and Blackmagic Driver |
| Linux | Media Express, Blackmagic Desktop Video Utility, and Blackmagic Driver |
| Firmware Upgrade | Loaded Through the Software Driver |
Operating System Compatibility
| Mac 15.0 Sequoia | |
| Mac 26.0 Tahoe or Later | |
| Windows 10, 64 Bit | |
| Windows 11 | |
| Linux |
Environmental Specifications
| Operating Temperature | 5 to 40 Degrees C, 32 to 104 Degrees F |
| Storage Temperature | Negative 20 to 45 Degrees C, Negative 4 to 113 Degrees F |
| Relative Humidity | 0 to 90 Percent Noncondensing |
