Blackmagic Design ATEM Television Studio 4K8 2TB Live Production Switcher
- Switches 8 12G SDI sources for HD and Ultra HD live production
- Converts frame rates and formats on all 8 video inputs
- Routes dedicated feeds through 10 12G SDI aux outputs
- Records directly to installed 2TB M.2 NVMe storage
- Streams directly using RTMP or SRT network protocols
- Creates layered layouts with 2 DVEs and SuperSource
- Provides 4 advanced chroma keyers and 2 downstream keyers
- Mixes audio through an integrated 58 channel mixer
- Displays configurable multiview layouts with up to 16 views
Blackmagic Design ATEM Television Studio 4K8 2TB brings switching, routing, streaming, recording, audio control, and monitoring into a single live production system with an integrated control panel. Eight 12G SDI inputs accept HD and Ultra HD sources, while input resynchronization and frame rate or format conversion help keep mixed sources aligned with the selected switcher standard.
Flexible Routing and Monitoring
Ten 12G SDI aux outputs provide dedicated feeds for external recorders, displays, or production destinations. The switcher also provides program output and multiview monitoring, with layouts configurable for up to 16 views. Four RJ45 ports form an integrated 10G Ethernet switch for control, networking, and connected workflows.
Streaming and Recording Built In
Direct streaming supports RTMP and SRT over Ethernet or a shared internet connection through USB C. Programs can be recorded to the installed 2TB M.2 NVMe storage or compatible external USB media. HD recording uses H.264 with AAC audio, while Ultra HD recording uses H.265 HEVC with AAC audio.
Creative Control for Live Production
Build layered productions with 2 DVEs, SuperSource, 4 advanced chroma keyers, 2 downstream keyers, 2 media players, and a 58 channel audio mixer. Talkback, camera control, macro buttons, a fader bar, joystick control, and a system LCD place core production tools directly on the integrated panel.
Video Connections
| SDI Video Inputs | 8 |
| SDI Video Outputs | 12 |
| SDI Rates | 1.5G, 3G, 6G, 12G |
| High Definition Multimedia Interface Compatible Video Outputs | 1 |
| SDI Aux Outputs | 10 |
| SDI Program Outputs | 1 |
| Video Input Resynchronization | All 8 Inputs |
| Frame Rate and Format Converters | All 8 Inputs |
Audio Connections
| Balanced Analog Audio Inputs | 2 x XLR |
| MADI Digital Audio Input | 1 x BNC, 32 Channels |
| Stereo Analog Audio Inputs | 2 x RCA |
| Talkback Input | 1 x 5 Pin XLR |
| Analog Audio Outputs | 4 x 1/4 Inch Jack |
| MADI Digital Audio Output | 1 x BNC, 64 Channels, Up to 50 Active |
| Talkback Output | 1 x 5 Pin XLR |
| SDI Audio Inputs | 4 Embedded Channels on All SDI Inputs |
| SDI Audio Outputs | 16 Assignable Channels |
| USB Audio Output | Digital Audio over USB C |
Timecode, Reference, and Talkback
| Timecode Connections | 1 x BNC Input, 1 x BNC Output |
| Reference Connections | 1 x BNC Input, 1 x BNC Output |
| Reference Formats | Tri Sync or Black Burst |
| Internal Timecode Generator | Yes |
| Talkback | RJ45 for Third Party Talkback Systems |
| Talkback Support | Yes |
| Mix Minus Support | Yes |
Webcam, Network, and Computer Connections
| Webcam Output | 2 x USB C Supporting 720p or 1080p at Program Frame Rate |
| Ethernet | 4 x RJ45 with Integrated Network Switch |
| Ethernet Rates | 10/100/1000/10G BASE T |
| Computer Interface | 2 x USB C with USB 3.0 Support |
| Remote | RJ12 with RS 422 Support |
| Control Panel Connection | Ethernet, Direct or Network Connection |
| Tally Output | Supported Through Blackmagic Design GPI and Tally Interface, Not Included |
HD Video Input Standards
| 720p | 50, 59.94, 60 |
| 1080i | 50, 59.94, 60 |
| 1080p | 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 |
Ultra HD Video Input Standards
| 2160p | 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 |
Video Processing
| SD Video Standards | None |
| SDI Compliance | SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081 1, SMPTE 2081 10, SMPTE 2082 1, SMPTE 2082 10 |
| Video Sampling | 4:2:2 |
| Color Precision | 10 Bit |
| Color Space | Rec 709 |
| SDI Auto Switching | Automatically Detects 1.5G SDI, 3G SDI Level A or B, 6G SDI, and 12G SDI |
| Processing Delay | Less Than 10 Lines When Genlocked and Using the Same Format as the Switcher |
| Down Conversion | 1 x Multiview |
Control Panel
| Mix Effects Rows | 1 |
| Direct Cross Points | 10 |
| Shifted Cross Points | 20 |
| Crosspoint Button Type | Tri Color LED |
| Crosspoint Label | 6 Rows, 24 Character LCD |
| Preview Transition | 1 |
| Source Select Bus | 1 |
| Dedicated Macro Buttons | 10 Plus Shift 10 |
| Transition Type Buttons | 5 |
| Transition Rate | Set Through System LCD Menu |
| Key Buttons | 8 |
| Aux Buttons | 12 |
| Fader Bar | 1 |
| Record Buttons | 2 |
| Stream Buttons | 2 |
| Downstream Key Transition Selectors | 6 |
| Fade to Black Buttons | 1 |
| System LCD Displays | 1 |
| Numeric Keypad | 1 |
| 3 Axis Joystick | 1 |
| Integrated Control Panel | Full Switching and Settings Control |
Keying and Effects
| Upstream Keyers | 4 |
| Downstream Keyers | 2 |
| Advanced Chroma Keyers | 4 |
| SuperSource | 1 |
| DVEs | 2 |
| Linear and Luma Keyers | 7 |
| Transition Keyers | 1 Stinger, 1 DVE |
| Total Layers | 8 |
| Pattern Generators | 7 |
| Color Generators | 2 |
| Routable Windows | 16 |
| Window Source Labels | Yes |
| Tally | Red for Program, Green for Preview |
Streaming
| Direct Streaming Protocols | RTMP and SRT |
| Streaming Connection | Ethernet or Shared Internet Connection Through USB C |
| Blackmagic Cloud Stream Router | Supported |
Recording
| Direct Recording | Internal M.2 Storage or External USB C Media |
| Internal Memory | 2TB M.2 NVMe Installed |
| HD Recording | H.264 MP4 with AAC Audio |
| Ultra HD Recording | H.265 HEVC with AAC Audio |
| Supported Media Formats | ExFAT, APFS, HFS Plus |
Multiview
| Multiview Outputs | 1 x 12G SDI and 1 x High Definition Multimedia Interface Compatible Output |
| Multiview Layouts | 16, 13, 10, 7, or 4 Views |
| Monitored Sources | Program, Preview, Inputs, Media Players, Downstream Keyers, SuperSource, Clean Feed |
| Optional Multiview Information | Source Labels and Audio Meters |
| Multiview Video Standard | HD or Ultra HD |
| Minimum Display Resolution | 1366 x 768 |
Media Players
| Media Players | 2 |
| Channels | Fill and Key for Each Media Player |
| Still Image Capacity | 20 |
| Still Image Formats | PNG, TGA, BMP, GIF, JPEG, TIFF |
| Clip Capacity | 2 Clips Up to 2160p60 |
| 720 HD Clip Length | 720 Frames |
| 1080 HD Clip Length | 360 Frames |
| 2160 UHD Clip Length | 90 Frames |
| Video File Format | TGA Sequence |
| Audio File Formats | WAV, MP3, AIFF |
Audio Mixer
| Audio Mixer | 58 Channels |
| Channel Modes | On, Off, Audio Follow Video |
| Metering | Level and Peak |
| Master Gain Control | Yes |
| Equalization | 6 Band Parametric EQ |
| Dynamics | Expander, Gate, Compressor, Limiter |
| Fairlight Live Integration | Supported |
Camera Control
| Compatible Camera Control | Focus, Iris, Zoom, Gain, White Balance, Tint, Shutter, ND Filter, Color Correction, Tally, Record Start and Stop |
Software
| Control Software | ATEM Software Control |
| Supported Computer Platforms | Mac and Windows |
| Software Updates | USB or Ethernet |
| Setup Utility | ATEM Setup Utility |
| Configuration | ATEM Software Control |
Operating System Compatibility
| Mac | macOS 14.0 Sonoma, macOS 15.0 Sequoia or Later |
| Windows | Windows 10 and Windows 11 |
Power
| Internal Power Supply | 100 to 240 VAC, 50/60 Hz with IEC C14 Socket |
| External Power Input | 1 x 4 Pin XLR, 12 VDC |
| Power Usage | 120 W |
Physical Installation
| Installation | Desktop or In Desk Mount |
Environmental
| Operating Temperature | 0° to 40° C (32° to 104° F) |
| Storage Temperature | -20° to 60° C (-4° to 140° F) |
| Relative Humidity | 0% to 90% non-condensing |
