- Canon EOS C70 Cinema Camera Kit with 24-105mm Zoom Lens, Built-in RF Mount, and Enhanced Scan Mode
- Handle Unit
- SS-1200 Shoulder Strap
- Battery Charger CG-A20
- Compact Power Adapter CA-CP200 L
- AC Power Cable
- Canon BP-A30 Battery Pack
- Microphone Holder Unit
- Show adapter Base/Knob/Screw (M4)
- Measure Hook
- Body Cap
- RF 24-105mm F4 L IS USM
- GPS Receiver
- Wi-Fi Adapter / Ethernet Adapter
- Mount Adapters
- Limited 1-Year Warranty
Canon EOS C70 Cinema Camera Kit with 24-105mm Zoom Lens, Built-in RF Mount, and Enhanced Scan Mode
- Cinema camera kit
- 35mm dual gain output (DGO) sensor
- 16 Plus stops of total dynamic range
- Features DV7 image processor
- Canon log 2 and 3, PQ, and HLG recording
- Features built-in RF Mount
- EF lens compatibility with mount adapter EF-EOS R 0.71x
- Provides direct touch control
- Approved for use in Netflix productions
- Improved Face Detection AF
The Canon EOS C70 Cinema Camera Kit offers exceptional cinematic capabilities in a compact package. Enjoy stunning images with a 4K Super 35mm DGO Sensor and all the built-in features you could ask for, including ND Filters, mini XLRs, a direct touch rotatable LCD screen, dual-pixel CMOS Autofocus, and excellent battery life. Making the EOS C70 even more powerful is its compatibility with Canon's expanding line of high-performance RF Lenses.
Impressive Image Quality
Get smooth blacks and bold colors. The EOS C70’s Super 35mm DGO Sensor generates 16+ stops of total dynamic range and maintains low noise levels to prioritize saturation for bright areas and lower noise for darker areas.
More Built-Ins, Less Add-Ons, Max Value
Start shooting from day one with all the built-ins you could ask for, including ND filters for various lighting conditions, mini XLRs for professional audio recording, and dual SD card slots for simultaneous recording in different formats. Access it all with one hand on the direct touch rotatable LCD screen, allowing for on-the-spot changes while holding the camera.
Serious Cinema In A Small Package
Control your dynamic range by choosing between Canon Log 2 or Canon Log 3 Gamma, and capture frame rates up to 120 fps in 4K or up to 180 fps in 2K CROP mode-all with electronic image stabilization. Enhance the EOS C70 further by synchronizing multi-camera productions via the built-in timecode port and adding Cinema RAW Light internal recording, Canon 709 Custom Picture Profile, XF-AVC Intra 4K 60p recording, and other new features via a free firmware upgrade.
Built To Be Taken Anywhere
Designed to go where you go, the EOS C70's unibody design exhibits a compact form factor and a built-in ergonomic grip that makes handheld shooting easy and comfortable.
Canon’s Rf System and Legendary Lenses
The EOS C70 is a cinema powerhouse all on its own and is engineered with a built-in RF mount for compatibility with Canon’s expanding line of high-performance RF Lenses. For increased flexibility, the EOS C70 is also compatible with Canon’s line of award-winning EF lenses using the Mount Adapter EF-EOS R 0.71x. This maintains a similar full-frame angle of view on the Super 35mm sensor but boosts the speed of the attached lens by an average of 1 stop.
Canon Super 35mm Dual Gain Output (DGO) Sensor, 16+ stops of Total Dynamic Range
The EOS C70 features Canon's next-generation Super 35mm Dual Gain Output (DGO) Sensor. This sensor is capable of a total dynamic range more than 16 stops and includes Canon’s exclusive Dual Pixel CMOS Autofocus technology. The DGO Sensor is an imaging system that generates a high dynamic range and maintains low noise levels by reading out each photodiode with two different gains. It combines the two with a saturation prioritizing gain for bright areas, and a lower noise prioritizing gain for darker areas.
Enhanced Clear Scan Mode
Firmware available in Summer 2023 will add improvements to the Clear Scan shutter mode to help reduce or virtually eliminate the flickering caused by some LED walls.
DV7 Image Processor
The EOS C70 features Canon's DV7 image processor, which takes the extensive RAW information captured from the imaging sensor and processes it for output. DV7 Image Processor is also the engine behind features such as high frame rate recording, Dual Gain Output (DGO) sensors, Dual Pixel Autofocus, HDR (PQ) output, Electronic Image Stabilization, and proxy recording.
Canon EOS C70 Cinema Camera Kit with 24-105mm Zoom Lens, Built-in RF Mount, and Enhanced Scan Mode
Imaging sensor
| Effective pixels | 4096 x 2160: when 4096 x 2160 or 2048 x 1080 is selected as the resolution (approx. 8.85 megapixels), |
|
|
| Total pixels | 4206 x 2280; approx. 9.6 megapixels |
| Sensor type | cmos |
| Sensor size | Super 35mm |
|
|
| Sensor modes | Super 35mm, super 16mm (cropped) |
| Pixel pitch | 6.4 m |
| Scanning system | progressive |
| Number of sensors | 1 |
| Filter | Rgb primary color filter (bayer array) |
| Imaging processor | dv 7 |
Lens System
| Lens Mount | Default mount: Rf mount |
| Zoom/focus preset | Not available |
| Shockless zoom | Not available |
| Digital teleconverter | Not available |
| Nd filter | Mechanical nd filter system with option of clear, 2, 4, and 6 stops; 8 and 10 stops in extended mode |
| Peripheral illumination correction | Available |
| Chromatic aberration correction | Available |
| Distortion correction | Available (rf lenses only) |
| Diffraction correction | Available |
Exposure and Metering
| Exposure modes | (1) manual exposure based on shutter setting, iris setting, iso/gain setting, and third filter setting |
|
|
| Metering modes | standard, spotlight and backlight |
| Gain | normal setting: -6 dB to 54 dB |
|
|
| Iso | 100 to 102,400 |
| Auto gain control (agc) | not available |
| Shockless gain | not available |
| Exposure compensation/ae shift | -2.0 to +2.0 in 0.25 point intervals |
| Shutter modes | 3 modes: off; speed; angle; slow shutter; clear scan |
|
|
| Shutter speed range | 59.94 hz/24.00 hz: 1/12 to 1/2000 |
|
|
| Shutter angle settings | 59.94 hz/50.00 hz/24.00 hz: 360, 240, 180, 120, 90, 60, 45, 30, 22.5, 15, 11.25 |
| Iris settings (ef) | can be set to 1/2 stop, 1/3 stop, or fine. |
|
Focus
| Focus control | dual-pixel CMOS AF with EOSxITR |
| Focus modes | Manual focus, Continuous AF, One-Shot AF, AF-Boosted MF, Face Detection AF |
|
Recording Selection
| System Frequency | 59.94 Hz, 50.00 Hz, 24.00 Hz |
|
|
| Mode | |
| XF-AVC | |
| Resolution | 4096x2160/ |
|
|
| Frame rates | 59.94p, 29.97p, |
|
|
| Mode | |
| MP4 | |
| Resolution | 4096x2160 or 3840x2160 |
| 2048x1080 or 1920x1080 | |
| 1280x720 | |
| Frame rates | 59.94p, 29.97p, 23.98p |
|
|
| Color gamuts | Cinema Gamut, BT.709, BT.2020 |
| Gamma curves | Canon 709, BT.709, Wide DR, Canon Log 2, Canon Log 3, PQ, HLG |
| N/A4 | Enabled for recording (including proxy) and output from each terminal |
Recording/ Codec
| Internal recording | RAW recording or cinema RAW Light: RAW HQ (high quality), RAW ST (standard quality), and RAW LT (light recording). |
| Video compression formats | XF-AVC; MPEG-4 AVC/H.264 (10bit, 8bit (proxy)) |
|
|
| File format | XF-AVC: MXF (OP-1a) |
|
|
| File system | SDHC card: (up to 32 GB): FAT32 |
|
|
| Maximum clip number | 999 (per media) |
Audio
| Recording format | Linear PCM; 4-Channel; 24-Bit; 48 kHz |
| Built-in microphone | Stereo/Monaural |
| External audio inputs | 2 Mini-XLR inputs (Auto and Manual level settings) |
|
|
| Recording channel selection | Up to 4-channel audio recording is supported. |
| XLR mic trimming | Available: -12 dB, -6 dB, 0dB or +12 dB |
| Limiter | Available |
| Recording level adjustment range | - Infinity to +18dB |
| Phantom power | Available; +48V |
| Headphone adjustment | 16 Settings; Volume is muted at lowest setting |
| Built-in speaker | Available; volume adjustable |
| 1KHz tone | Available (off, -12, -18, or -20 dB) |
Features and Performance
| Playback | |
| Clip display | 3x4 Index Display. |
| Clip playback | Forward Search (x5, x15, x60), reverse search (x5, x15, x60), forward frame advance, reverse frame advance, record review, skip to next clip, skip to the previous clip |
| Clip information display | Clip metadata display, custom picture settings |
| Playback functions | Clip melete |
| Photo playback | index, single playback, delete, protect |
| Slow and fast motion recording | |
| Super35 | XF-AVC: 23.98P/24P: 12-120 |
|
|
| Super16 | (Crop)XF-AVC: 23.98P/24P: 12-180 |
|
|
| Super35 | MP4: 23.98P/24P: 12-120 |
|
|
| Super16 | |
|
LCD Monitor
| Type | 3.5-inch (8.8 cm diagonal) color wide-screen LCD |
| Approx. 2,760,000 dots (1280 x RGB x 720), | |
| Aspect ratio | 16:9 |
| Field of view coverage | 100 percent |
| Display adjustments | Brightness, contrast, color, sharpness, and luminance |
Input/Output
| Time code In/Out | Yes; BNC Connector (Input and Output) |
| HDMI | Yes (Type A) |
|
|
| Audio input terminal | 2 – Balanced 3-pin XLR (Mic level, mic level with phantom power and line level) |
|
|
| Headphone jack | Available; 3.5mm stereo mini-jack |
| Remote terminals | Remote A (Standard – LANC Compatible or RC-V100) |
|
|
| USB | Available |
| CCU | Remote controller RC-V100 (Optional) |
Power
| Supply | 14.4V DC (Battery Pack) |
| Power terminal | 14.4 V DC (battery pack), 24.0 V DC (DC IN) |
| Battery | BP-A Series (BP-A30, BP-A60) |
| Compact power adapter | CA-CP200L (for Camera and Battery charger CG-A20) |
Other
| Dimensions | (Width x height x depth, excluding cable and grip belt) |
| Body Only | Approx. 130.2 x 160 x 115.9 mm |
| Weight | RF Camera body: Approx. 1.17 Kg (2.6 lbs) |
|
|
| Temperature and Humidity | |
| Performance requirements | 0 degree C to 40 degreeC, 85 percent relative humidity |
| Operating requirements | -5 degrees C to 45 degrees C, 60 percent relative humidity |
| Language support | English, japanese, chinese, german, spanish, french, italian, korean, and Russian |
| Time and date | Automatic calendar range: January 1st, 2020 through December 31, 2050 |
| World Clock | World Clock Support: UTC Time Setting: Setting range: +14:00 to -12:00 |
Accessories
| GPS Receiver | GP-E2 with Interface cable IFC-40AB III / IFC-150AB III) Via USB-C |
| Wi-Fi Adapter / Ethernet Adapter | |
| Wi-fi | |
| Asus | usb-ac68: requires usb to usb-c adapter |
| Asus | usb-ac56: requires usb to usb-c adapter |
| Tp-link | archer t9uh: requires usb to usb-c adapter |
| Edimax | ew-7822uac: requires usb to usb-c adapter |
| i-o data | wn-ac867u dwa-182(c1) |
| *not compatible with dwa-182(d1) | |
| Ethernet | |
| Startech | us1gc30w |
| Tp-link | ue300: requires usb to usb-c adapter |
| Mount Adapters |
|
