- 1 x CyberPower CP700PFCRM1U PFC Sinewave Rackmount UPS
- 2 x Rackmount Brackets
- 1 x USB-A and B Type Cable
- 1 x User Manual
Trusted & Verified
CyberPower CP700PFCRM1U (Black) PFC Sinewave 1U Rackmount UPS System 700VA 400W
- 700 VA and 400 W capacity for active PFC-compatible equipment
- Sine wave battery backup supports orderly shutdown during outages
- 10.5-minute runtime at half load and 1.5-minute runtime at full load
- Six NEMA 5-15R outlets with four battery-plus surge-protected connections
- 1150 J surge suppression with EMI and RFI filtration
- 1U metal rackmount chassis measures 9.04 inches deep
- Color multifunction LCD shows battery and power conditions
- USB, SNMP, PowerPanel Business, and optional RMCARD205 management support
The CyberPower CP700PFCRM1U is a compact 1U rackmount UPS built for equipment that benefits from sine wave battery backup and active PFC power source compatibility. With 700 VA and 400 W capacity, it supports security systems, audio and visual equipment, networking hardware, workstations, and other rack-based electronics. Its 9.04-inch chassis depth helps conserve rack space while providing battery backup, surge suppression, voltage regulation, and power monitoring in one unit.
Sine Wave Battery Backup
The UPS delivers sine wave output with 10.5 minutes of runtime at half load and 1.5 minutes at full load. This gives connected equipment time for a controlled shutdown when utility power fails. Two sealed lead-acid batteries are hot swappable and user replaceable, and the typical recharge time is 8 hours. Four NEMA 5-15R outlets provide battery plus surge protection, while two additional NEMA 5-15R outlets provide surge-only protection.
Voltage, Surge, and Data Line Protection
Line interactive topology and Automatic Voltage Regulation correct minor input fluctuations without immediately switching to battery operation. The CP700PFCRM1U provides 1150 J of surge suppression, EMI and RFI filtration, and RJ45 network data line protection. GreenPower UPS Bypass Technology allows stable utility power to bypass the transformer, reducing energy use, operating noise, and heat. The unit is Energy Star certified.
Short Depth Rackmount Monitoring
The black metal chassis is 1U high and fits racks as shallow as 14 inches. A multifunction color LCD presents battery and power conditions at a glance. USB and SNMP communication work with PowerPanel Business software for monitoring and management, while optional RMCARD205 hardware supports remote management. A 10-foot cord with a NEMA 5-15P right-angle plug provides flexible rack placement.
General
| Energy Saving | GreenPower UPS Bypass Technology |
| Energy Star Certified | Yes |
| UPS Topology | Line Interactive |
Battery:
| Battery Quantity | 2 |
| Battery Type | Sealed Lead Acid Battery |
| Hot Swappable | Yes |
| Replacement Battery Cartridge | RB0690X2 |
| Replacement Battery Cartridge Quantity | 1 |
| Runtime at Full Load | 1.5 minutes |
| Runtime at Half Load | 10.5 minutes |
| Typical Recharge Time | 8 hours |
| User Replaceable Battery | Yes |
Input:
| Adjustable Voltage Range | 97 VAC to 144 VAC |
| Circuit Breaker | 15 A |
| Cord Length | 10 feet (3.0 m) |
| Input Frequency Range | 57 Hz to 63 Hz |
| Input Plug Type | NEMA 5-15P |
| Input Voltage Range | 88 VAC to 144 VAC |
| Nominal Input Voltage | 120 VAC |
| Plug Style | Right Angle, 45 Degree Offset |
Output:
| Automatic Voltage Regulation | Single Boost |
| On AC Waveform | Sine Wave |
| On Battery Frequency | 60 Hz ± 1% |
| On Battery Voltage | 120 VAC ± 10% |
| On Battery Waveform | Sine Wave |
| Outlet Type | 6 NEMA 5-15R |
| Outlets, Battery and Surge Protected | 4 |
| Outlets, Surge Only Protected | 2 |
| Outlets, Total | 6 |
| Output Power Factor | 0.57 |
| Overload Protection | Internal Circuitry Limiting, Circuit Breaker Protected |
| Typical Transfer Time | 8 ms |
| USB Charge Port | No |
| Capacity | 700 VA |
| Output Power | 400 W |
Surge Protection and Filtering:
| EMI and RFI Filtration | Yes |
| Network Protection RJ45 | 1 In / 1 Out (10/100/1000) |
| Surge Suppression | 1150 J |
Management and Communications:
| Audible Alarms | Battery Mode, Low Battery, Overload, Fault |
| HID Compliant USB Port | Yes |
| LCD | Multifunction LCD |
| LED Indicators | Power On, Wiring Fault |
| Management Cable | USB Cable |
| SNMP / HTTP Remote Monitoring | Yes, with optional RMCARD205 |
| Serial Port | 1 Dry Contact |
| Software | PowerPanel Business |
Physical:
| Color | Black |
| Form Factor | Rackmount |
| Material of Construction | Metal |
| Rack Height | 1U |
Dimensions:
| Physical Dimensions, W x H x D | 43.31 cm x 4.39 cm x 22.96 cm |
| Physical Dimensions, W x H x D | 433 mm x 44 mm x 230 mm |
| Physical Weight | 8.3 kg |
| Physical Weight | 18.3 lb |
Shipping Dimensions:
| Shipping Weight | 9.01 kg |
| Shipping Weight | 19.86 lb |
| Shipping Dimensions, W x H x D | 53.01 cm x 15.49 cm x 27.99 cm |
| Shipping Dimensions, W x H x D | 20.87 inches x 6.1 inches x 11.02 inches |
| Shipping Dimensions, W x H x D | 530.1 mm x 154.94 mm x 279.91 mm |
Environmental:
| Operating Elevation | 0 feet to 10,000 feet (0 m to 3,048 m) |
| Operating Relative Humidity | 0% to 95% (noncondensing) |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Elevation | 0 feet to 50,000 feet (0 m to 15,239 m) |
| Storage Relative Humidity | 0% to 95% (noncondensing) |
| Storage Temperature | 5 °F to 113 °F (minus 15 °C to 45 °C) |
Certifications:
| Environmental | RoHS Compliant |
| Safety | UL1778, CSA C22.2 No. 107.3, FCC Class B, DOE |
Warranty:
| Connected Equipment Guarantee Amount | $300,000 |
| Connected Equipment Guarantee | Lifetime |
| Product Warranty | 3 Year Limited Warranty |
