Hollyland Pyro 5 4K All-In-One 5.5 Inch Wireless Transceiving Monitor with HDMI/SDI & Camera Control
Expected around August 2026. Preorder Now for first access when it is available.
First come, first served — limited availability.
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
The Pyro 5 4K features a 5.5-inch wireless monitor with do-it-all performance. With dual-band transmission, 4-way monitoring via Broadcast Mode, direct camera control, smart channel selection, and a 1500-nit daylight-viewable screen, it combines multiple functions into one compact tool. Proxy recording and RTMP live streaming make the Pyro 5 4K more than just a monitor—it's your multi-tasking hub on set, built to simplify and speed up every step of production.
Features:
- All-in-one transmitter, receiver, and monitor solution
- Broadcast mode supports one transmitter with up to four receivers
- Non-Broadcast mode supports up to four receivers for monitoring
- Wireless transmission on 2.4 GHz and 5 GHz frequency bands
- Minimum 60 ms latency in an interference-free environment (1080p60)
- Up to 1,300 ft (400 m) line-of-sight range (1 TX + 2 RX)
- Supports proxy recording
- Supports 3D LUT analysis and import
- TX mode supports HDMI 4K30 input and loop-out
- TX mode supports SDI 1080p input
- TX mode supports streaming
- RX mode supports HDMI 1080p output
- Flexible power options with locking DC input and NP-F batteries
- Supports automatic frequency hopping
- Automatically selects a clear frequency channel at startup
- Extended battery life in monitor mode with Wi-Fi transmission disabled
- Professional image analysis tools including Luma Waveform, RGB Waveform, Vectorscope, and Histogram
- Monitoring assist functions include Zebra Pattern, Focus Assist, False Color, Aspect Mark, Anamorphic, and Crosshatch
- Camera control
- 2.412 - 2.484 GHz
- 5.150 - 5.250 GHz
- 5.250 - 5.350 GHz
- 5.725 - 5.850 GHz
- Non-Broadcast: 20 MHz
- Broadcast: 40 MHz
- Non-Broadcast: -85 dBm
- Broadcast: -80 dBm
- DC Input (2.0 mm Locking Connector)
- NP-F Battery Compatible
- NP-F: 6V–16V
- DC In: 10V–18V DC
- TX Mode: < 18.9W
- RX Mode: < 16W
Display
| Screen Size | 5.5 Inch Touchscreen |
| Resolution | 1920 × 1080 |
| Aspect Ratio | 16:9 |
| Brightness | 1,500 nits |
| Contrast Ratio | 1000:1 |
| Color Gamut | Rec.709 |
Video Input Ports
| HDMI Input | HDMI 1.4b |
| SDI Input | 3G-SDI |
Video Output Ports
| HDMI Loop-Out | HDMI 1.4b (TX Mode) |
| HDMI Output | HDMI 1.4b (RX Mode) |
HDMI Input Formats
| 720p50/59.94/60 | |
| 1080i50/59.94/60 | |
| 1080p23.98/24/25/29.97/30 | |
| 1080p50/59.94/60 | |
| 3840 × 2160p23.98/24/25/29.97/30 |
HDMI Loop-Out Formats
| 720p50/59.94/60 | |
| 1080i50/59.94/60 | |
| 1080p23.98/24/25/29.97/30 | |
| 1080p50/59.94/60 | |
| 3840 × 2160p23.98/24/25/29.97/30 |
SDI Input Formats
| 1080p50/59.94/60 (Level A) | |
| 1080p50/59.94/60 (Level B) | |
| 1080i50/59.94/60 | |
| 1080p23.98/24/25/29.97/30 | |
| 1080psf23.98/24 | |
| 1080psf25/29.97/30 | |
| 720p50/59.94/60 |
HDMI Output Formats
| 720p50/59.94/60 | |
| 1080i50/59.94/60 | |
| 1080p23.98/24/25/29.97/30 | |
| 1080p50/59.94/60 |
Color Depth Capability
| TX Mode HDMI Input | YUV 4:2:2 / YUV 4:4:4, 8-bit |
| RX Mode HDMI Output | RGB 888 |
Audio Format
| TX Mode | HDMI 1.4b 2-Channel Audio |
| RX Mode | HDMI 1.4b 2-Channel Audio |
Wireless Transmission
| Frequency Bands | |
| Latency | Approx. 60 ms (1080p60) |
| Bandwidth | |
| Transmit Power | < 23 dBm |
| Receiver Sensitivity |
Antenna
| Connector Type | SMA Male |
Recording & Encoding
| Video Encoding | H.264 |
| Maximum Video Bitrate | 12 Mbps |
Audio & Data Ports
| Headphone Output | 3.5 mm Jack |
| Upgrade Port | USB-C (USB 2.0 OTG) |
| Storage Slot | SD Card Slot |
Power
| Power Input | |
| Input Voltage | |
| Power Consumption |
Physical Specifications
| Dimensions (L × W × H) | 151.6 × 102.3 × 40.5 mm (5.97 × 4.03 × 1.59 inch) |
| Weight | Approx. 410 g (14.5 oz) |
Environmental
| Operating Temperature | -10°C to 45°C |
| Storage Temperature | -40°C to 60°C |
