Monitoring a large area comes with its share of obstacles. Usually, they require several security cameras to ensure proper coverage. A PTZ security camera such as this, however, can overcome many of these issues. With its ability to pan left and right, tilt up and down, and zoom in incredibly close thanks to a 12x optical zoom lens, this PTZ camera can do it all. This camera also features vivid 2K resolution recording, along with a fully weatherproof exterior for year-round protection.
Versatile
The PTZ security camera can move its lens in virtually any direction, as well as being able to zoom in on objects in the distance. This PTZ camera features full 360-degree panning rotation, a -15~90 degrees tilt ability, a 12x optical zoom, and 16x digital zoom to focus on even the finest details.
Create Unlimited PTZ Tours
Expand your security coverage with fully automated PTZ tours. These tours are designed to cycle through a number of user-defined location presets. All of the pan, tilt and zoom features can be used during a tour. You can also create a simple pattern movement that will automatically cycle the camera's viewpoint between two presets. These automated tour and pattern settings can be found in the NVR's PTZ settings menu. You can even program your DVR to change the tour/pattern based on the time of day within these settings.
Vivid 2K SuperHD Resolution
An advanced 4MP image sensor is at the core of this PTZ security camera. This allows for stunning 2K (2592x1520) recording to ensure premium quality live-viewing and recording. It also allows for greater digital zooms if you need to zoom in on something deep in the distance while reviewing footage.
See in Color - Even at Night
This PTZ camera has an incredible IR night vision range up to 330-feet (100m) in total darkness. Furthermore, adding additional lighting around the camera will automatically trigger our revolutionary Color Night Vision (CNV) technology. This important feature will add an additional level of visual information that can help identify people or objects and increase contrast for easier detection and recognition.
Enhanced Security Monitoring With HDR
Your security camera uses HDR (High Dynamic Range) technology that works to ensure you capture the most important details, regardless of lighting conditions. Dynamic range is measured as the difference between the brightest point and the darkest point of the video. HDR technology uses this difference to automatically adjust the picture's brightness, resulting in optimized, highly detailed security video.
Enhanced Clarity in Low-Light Situations
Your camera uses DNR (Digital Noise Reduction) technology to filter out noise from low-light settings as well as any noise caused by motion. By eliminating graininess, your camera provides a cleaner, more accurate image with better clarity, sharpness, and improved motion detection. Not only does DNR reduce noise, but it reduces video file sizes as well, giving you greater disc space for storage.
Remote Connectivity for Easy PTZ Adjustments
Connect this PTZ camera to a compatible Lorex NVR to enable remote viewing and adjustments. Simply download the NVR's mobile app and you will be able to see the camera's live view and control the camera's movements straight from your smartphone or tablet.
Flexible PoE Installation
There is no need to run special wiring to install this camera - power to the camera, video transmission and PTZ controls are all provided by the included 100-feet ethernet network cable for easy setup.
All-Weather Security Camera
This PTZ camera is rated IP66. This ensures that it is safe for outdoor installations. Its heavy-duty metal housing is well equipped to withstand both the elements and vandalism.
Camera/Video
| Field of View | Horizontal: 54.7 to 4.54 Degree |
| Night Vision | Yes |
Features
| Outdoor Use | Yes |
| Auto-Detection | No |
| Motion Detection | No |
General
| Color | White |
| Weight | 6.6 lb / 3kg |
Lorex 4MP Outdoor PTZ Network Dome Camera with Color Night Vision
| Image sensor | 1/3-inch, CMOS 4 MP |
| Video format | NTSC / PAL |
| Effective pixels | 2592 (H) x 1520 (V) |
| Resolution | Up to 4MP |
| Range | 0 to 360 degrees pan (endless); -15 to 90 degrees tilt |
| Pan/tilt speed | Max 200-degree/sec pan; Max 120-degree/sec tilt |
| Zoom | 12x optical zoom and 16x digital zoom |
| Scan system | Progressive |
| Synchronization | Internal |
| S/N ratio | ≥50dB |
| Iris | DC Auto Iris with hall-effect |
| Min. illumination | 0.1 lux in color; 0.01 lux in black and white |
| Lens/lens type | 5.3-64mm, f/1.6-4.4 / zoom module |
| Field of view (horizontal) | 54.7 to 4.54 degree |
| Day/night | Auto (ICR) / Color / B/W |
| Termination | RJ45 (10Base-T/100Base-TX) / DC Jack |
| Video output | IP |
| Power requirement | PoE+ (802.3at); 12V DC (Optional) |
| Power consumption | Max. 2.2A / 26W |
| Operating temperature range | -40 to 158 degree-F / -40 to 70 degree-C |
| Operating humidity range | <90%RH |
| Indoor/outdoor | Both (IP66) |
| Weight (camera alone) | 6.6 lb / 3kg |
| Weight (camera and wall mount) | 8.6 lb / 3.9 kg |
