Lorex 4K 16 Camera Capable (8 Wired + 8 Fusion Wi-Fi ) NVR
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
General
| Video Transmission Technology | IP |
| Channels | 16 Channels / Lorex Fusion Wi-Fi |
Inputs/Outputs
| Video Input | 8 x PoE, 8 x Wi-Fi Fusion |
| Video Outputs | 1 × VGA / 1 × HDMI |
| Audio Input | 1 x RCA |
| Audio Output | 1 x RCA |
Display
| Display Output Resolution | Up to 4K UHD |
| Live Display | 1, 4, 8, 9, 16 |
| Live Display Speed (Max) | 480fps NTSC / 400fps PAL |
| OSD | On/Off |
| System Navigation | USB Mouse |
Recording
| Recording Resolution | 12MP (16:9) and 4K+ (11.3MP 16:9) |
| Recording Frame Rate | 12MP (16:9) and 4K+ (11.3MP 16:9) |
| Recording Schedule | Continuous, Motion, Smart Motion (Person, Vehicle, Face), Alarm, Day, Hour per channel |
| Back-up File Format | DAV / AVI / MP4 |
| Video Compression | H.265 / H.264 |
Playback
| Simultaneous Playback | Up to 4 channels, synchronized |
| Playback Speed | x2, x4, x8, x16, 1 min, 5 min, 15 min, 30 min |
| Search | Time/Date, Motion Events, Smart Motion (Person/Vehicle), Attribution (Clothes Color, Vehicle Color, Number) |
Storage
| Hard Drive Bays | 1 Bay |
| Hard Drive Capacity | 1 SATA port, up to 16 TB |
| Backup Media | USB Flash Drive, USB HDD |
Special Features
| Smart Motion Detection Support | Yes (Person and Vehicle) |
| Wired/Wireless Fusion Support | Yes |
| Lorex Sensor Compatible | Yes |
| Face Detection Support | Yes |
| Mask Detection Support | Yes |
| Package Detection | Yes (Missing & Left Behind) |
| Animal Detection | Yes |
| Active Deterrence Support | Yes |
| Active View Support | Yes |
| Selectable Siren Support | Yes |
| Panic Button | Yes |
| Smart Search | Yes |
| Attribution Search | Yes (Clothes Color, Vehicle Color, Number) |
Smart Home
| Voice Control | Amazon Alexa, Google Assistant |
| Streaming Options | Chromecast, Amazon Echo Show, Google Home Hub |
| Matter Support | Yes |
Connectivity
| Mobile Viewing | Android, iOS |
| Compatible App | Lorex Home |
| PC/Mac Remote Viewing | Yes / Lorex Cloud client |
| Email Notification | Text and Snapshot |
| Network Interface | 10/100 Base-TX, RJ45 |
| Network Bit Rate | 80Mbps total, 48–8192 kbps per camera |
| DDNS | Yes (Optional) |
| USB Interface | USB 2.0 × 2 |
Additional Specifications
| Firmware Upgrade | USB / Network |
| Watchdog Function | Yes |
| Power Consumption | Approx. 8.3W (HDD excluded) |
| Supply Voltage | 100–240VAC, 50/60Hz, DC 53V/1.8A |
| Total PoE Power Output | 25.5W per port, 72W total |
| Unit Dimensions | 12.9 × 9.6 × 2.1 in (328 × 245 × 53 mm) |
| Unit Weight | 2.75 lbs (1.26 kg, HDD excluded) |
| Operating Temperature | 14° to 131°F (-10° to 50°C) |
| Humidity | 10% to 90% RH |
What's in the Box
| NVR Unit | 1 × 4K+ Fusion NVR |
| Ethernet Cable | 1 × |
| HDMI Cable | 1 × |
| Power Adapter | 1 × |
| USB Mouse | 1 × |
| Quick Setup Guide | Included |
Package Details
| Package Weight | 6.6 lb (2.99 kg) |
| Package Dimensions | 15.51 × 13.2 × 5.4 in (394 × 335 × 137 mm) |
| Package Volume | 0.64 cbf (0.018 cbm) |
