Promise Technology Pegasus32 R6 24TB 6-Bay Thunderbolt 3 RAID Array...
Take your creative projects to the next level with the Pegasus32 R6 24TB RAID Array from Promise Technology. Designed for photographers, videographers, and content creators, this powerhouse delivers lightning-fast performance, massive storage, and rock-solid data protection.
With six hot-swappable 4TB 7200 RPM SATA III drives and a hardware RAID controller supporting RAID 0, 1, 1E, 5, 6, 10, and 50, you can achieve up to 2800 MB/s transfer speeds while keeping your data safe. Drives come pre-configured in RAID 5 for optimal balance of performance and protection.
Seamless connectivity via dual Thunderbolt 3 ports (40 Gb/s) ensures ultra-fast transfers and daisy chaining multiple devices. One port supports up to 85W charging, while the second provides up to 15W, keeping your devices powered. Both ports are backward compatible with USB 3.2 Gen 2 (10 Gb/s) for versatile connectivity. A DisplayPort 1.4 lets you connect stunning 8K displays for large, highly detailed projects.
The array is pre-formatted for macOS 10.14+ and can easily be reformatted for Windows 10. Plus, it comes with ChronoSync Pegasus Edition, a powerful software for backups, file syncing, cloning, and cloud storage redundancy, so your work is always protected.
24TB Total Storage Capacity
Provides massive space for large creative projects, including 4K/8K video, high-resolution photos, and extensive file libraries.
Six Hot-Swappable 4TB 7200 RPM SATA III Drives
Easily replace or upgrade drives without powering down, ensuring uninterrupted workflow and easy maintenance.
Hardware RAID Controller with Multiple RAID Options
Supports RAID 0, 1, 1E, 5, 6, 10, and 50, offering flexible configurations for speed, redundancy, or a balance of both.
Pre-Configured RAID 5
Optimized for data protection and performance out of the box, minimizing setup time for creative professionals.
Ultra-Fast Data Transfer Up to 2800 MB/s
Ensures smooth handling of large files, fast backups, and seamless editing without lag.
Dual Thunderbolt 3 Ports (40 Gb/s)
High-speed connectivity for fast transfers, daisy chaining multiple devices, and power delivery (up to 85W & 15W).
Backward Compatible with USB 3.2 Gen 2 (10 Gb/s)
Compatible with a wide range of systems for versatile connectivity beyond Thunderbolt 3 devices.
DisplayPort 1.4-8K Display Support
Connect ultra-high-resolution displays for detailed projects, video editing, or large-scale design work.
Pre-Formatted for macOS, Reformat for Windows
Ready to use with macOS 10.14+, with the option to reformat for Windows 10 systems.
Bundled ChronoSync Pegasus Edition
Powerful software for automated backups, file synchronization, cloning drives, and redundant cloud storage to safeguard your work.
Main
| Capacity | 24 TB |
| Interface | Thunderbolt |
| Configuration | Core |
| Storage Type | HDD |
| Connection | 2x Thunderbolt 3 (40Gb/s) |
| Hard Drive Type | Desktop |
| Drive Speed/Type | 7200 rpm |
| Raid | RAID 1 |
| Color | Black |
Key Features
| 24TB total storage with 6 × 4TB SATA III 3.5" HDDs (7200 RPM) | |
| Preconfigured in RAID 5, supports RAID 0/1/5/6/10/50/JBOD | |
| Transfer speeds up to 2800 MB/s | |
| 6 × hot-swappable 3.5" SATA III drive bays | |
| Dual Thunderbolt 3 ports (40 Gb/s) and DisplayPort 1.4 | |
| PMC Sierra 8067 processor with 1 GB DDR3 memory | |
| Compatible with macOS 10.14 or later and Windows 10 | |
| Kensington Security Slot for physical security | |
| Efficient cooling with 92 mm fan | |
| Certified for BIS, BSMI, CE, FCC, RCM, TUV, VCCI, cTUVus |
Storage
| Total Capacity | 24 TB |
| Included Drives | 6 × 4TB SATA III 3.5" HDDs (7200 RPM) |
| RAID Support | 0, 1, 5, 6, 10, 50, JBOD |
| Transfer Rate | Up to 2800 MB/s |
| Drive Bays | 6 × 3.5" SATA III (Hot-Swap) |
Connectivity
| Ports | • 2 × USB-C Thunderbolt 3 (40 Gb/s) • 1 × DisplayPort 1.4 |
Computing
| Processor | PMC Sierra 8067 |
| Memory | 1 GB DDR3 @ 1866 MT/s |
Compatibility
| OS Compatibility | macOS 10.14 or later, Windows 10 |
| Installed OS | None |
| Mobile App | Not supported |
Security
| Encryption | None |
| Security Features | Kensington Security Slot |
Power & Cooling
| Input Power | 100–230 VAC, 50/60 Hz |
| Power Supply | 1 × 250 W |
| Cooling | 1 × 92 mm Fan |
Physical & Environmental
| Dimensions | 9.8 × 9.3 × 7.4 in / 248.9 × 236.2 × 188 mm |
| Weight | 20.1 lb / 9.1 kg (with drives) |
| Operating Temp | 41–95°F / 5–35°C, 10–95% humidity |
| Storage Temp | -40–158°F / -40–70°C, 5–95% humidity |
| Certifications | BIS, BSMI, CE, FCC, RCM, TUV, VCCI, cTUVus |
Packaging
| Package Weight | 25 lb |
| Box Dimensions (L×W×H) | 16.9 × 15.6 × 11.9 in |
