- 1 x Uniview NVR501-04B-P4 4 Channel Network Video Recorder
Trusted & Verified
Uniview NVR501-04B-P4 4 Channel 8MP Network Video Recorder with PoE, No HDD
- 4-channel NVR for IP camera recording
- 4 independent PoE camera ports support plug-and-play installation
- Records supported streams at resolutions up to 16 MP
- 80 Mbps incoming and 64 Mbps outgoing network bandwidth
- Ultra 265, H.265, and H.264 decoding support
- One SATA interface supports a hard drive up to 24 TB
- ANR technology enhances storage reliability during network interruptions
- Supplied without an installed HDD
The Uniview NVR501-04B-P4 is a 4-channel network video recorder for IP camera systems that need integrated PoE connectivity, flexible local storage, and high-resolution recording. Four independent PoE network interfaces simplify camera connection by carrying data and power through the recorder. The unit ships without an installed HDD, so storage can be selected for the recording plan.
High Resolution Recording and Display
The recorder supports recording resolutions up to 16 MP and decodes Ultra 265, H.265, and H.264 video formats. Its high-definition digital video output supports resolutions up to 3840 x 2160 at 30 Hz, while a VGA output supports up to 1920 x 1080 at 60 Hz. Incoming network bandwidth reaches 80 Mbps, with outgoing bandwidth up to 64 Mbps.
Storage and Network Resilience
One SATA interface supports a hard drive up to 24 TB, subject to operating conditions and drive size. ANR technology enhances storage reliability when the network is disconnected. The recorder also supports 4-channel smart functions from compatible IP cameras, including Face Detection, SIP, and UMD, plus search tools for people, vehicles, and general events.
For installation flexibility, the NVR includes one 10 M/100 M Ethernet interface, rear USB 2.0 and USB 3.0 ports, RCA audio input and output, and support for 128 remote users. The 260 mm x 222 mm x 47 mm chassis fits compact recorder installations while providing four PoE ports with up to 30 W per port and 50 W total.
General
Product:
| Model | NVR501-04B-P4 |
| Product Type | 1U Network Video Recorder |
| IP Video Input | 4 channels |
| Installed HDD | None |
Decoding:
| Decoding Format | Ultra 265, H.265, H.264 |
| Ultra 265 and H.265 Decoding Capability | 2 x 16 MP at 30 fps, 2 x 12 MP at 30 fps, 4 x 4K at 30 fps |
| H.264 Decoding Capability | 2 x 16 MP at 30 fps at 4800 x 2688, 2 x 12 MP at 30 fps, 2 x 4K at 30 fps, 4 x 5 MP at 30 fps |
| Per Channel Resolution Limit | 8192 pixels in length and 4096 pixels in width |
| Audio Compression | G.711A, G.711U |
Network:
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 64 Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4 |
| Browser Plugin Support | IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
| Cloud Upgrade | Supported |
| ANR | Supported |
Video and Audio Input:
| IP Video Input | 4 channels |
| RCA Audio Input | 1 channel |
Video and Audio Output:
| High Definition Multimedia Interface Compatible Output | 4K 3840 x 2160 at 30 Hz, 1920 x 1080 at 60 Hz, 1920 x 1080 at 50 Hz, 1600 x 1200 at 60 Hz, 1280 x 1024 at 60 Hz, 1280 x 720 at 60 Hz, 1024 x 768 at 60 Hz |
| VGA Output | 1920 x 1080 at 60 Hz, 1920 x 1080 at 50 Hz, 1600 x 1200 at 60 Hz, 1280 x 1024 at 60 Hz, 1280 x 720 at 60 Hz, 1024 x 768 at 60 Hz |
| RCA Audio Output | 1 channel |
| Live View Display | 1/4 |
| Corridor Mode Screen | 3/4 |
Two Way Audio:
| Two Way Audio | 1 channel RCA using the audio input and output |
Snapshot:
| FTP, Schedule, Event Snapshot | 4 channel snapshot, maximum D1 720 x 576 video resolution with D1 snapshot resolution |
Recording:
| Recording Resolution | 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080P, 960P, 720P, D1, 2CIF, CIF |
| Synchronous Playback | 4 channels |
Smart Functions:
| Smart by IPC | Total 4 channels Face Detection, SIP, UMD |
| VCA Search | Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map |
Alarm:
| General Alarm | Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording or Snapshot Abnormal |
GUI Languages:
| GUI Language Support | Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish Latin America, Portuguese Brazil, Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
Hard Disk:
| SATA | 1 SATA interface |
| Capacity | Up to 24 TB for each HDD, subject to environmental temperature and hard disk size |
| Storage Temperature Note | Environment temperature for use should not exceed 40 degrees Celsius |
External Interface:
| Network Interface | 1 RJ45 10 M/100 M self adaptive Ethernet interface |
| USB | Rear panel, 1 x USB 2.0 and 1 x USB 3.0 |
| RS485 | Not Available |
| RS232 | Not Available |
| Alarm Input | Not Available |
| Alarm Output | Not Available |
| Power Supply | DC 48 V, 1.35 A |
PoE:
| PoE Interface | 4 RJ45 10 M/100 M self adaptive Ethernet interfaces |
| PoE Power | Up to 30 W per port, up to 50 W total |
| Supported Standards | IEEE 802.3at, IEEE 802.3af |
Working Environment:
| Working Temperature | Minus 10 degrees Celsius to 55 degrees Celsius, 14 degrees Fahrenheit to 131 degrees Fahrenheit |
| Working Humidity | Up to 90 percent RH, noncondensing |
| Power Consumption Without HDD | Up to 10 W |
Dimensions:
| Weight Without HDD | Up to 1.1 kilograms, 2.43 pounds |
| Dimensions | 260 millimeters x 222 millimeters x 47 millimeters, 10.2 inches x 8.7 inches x 1.8 inches |
Certification:
| Certifications | CE, FCC, UL, RoHS, WEEE |
| CE Standards | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
| FCC | Part 15 Subpart B |
