Xenarc Technologies 7-Inch Touchscreen LCD Monitor with HDMI, DVI, VGA and AV Inputs
Couldn't load pickup availability
Product highlights
Product highlights
In the box
In the box
Free standard shipping
Free standard shipping
*Orders placed before 1 PM EST Mon - Thur will ship the same day. Orders placed beyond these hours will be shipped the next business day. Exclusions apply. See shipping policy
Free Local Pickup
Free Local Pickup
Please call for store stock availability. Requests made before 2:30 PM EST can be available for next-day pickup. Learn more
Xenarc Technologies is the leading manufacturer of 7-inch touchscreens display monitors also knows as 7-inch LED LCD HDMI screen panels with HDMI Video Signal input and an advanced 7-inch touch panel. This 7-inch touchscreen display monitor unit incorporates the latest LED backlight technology for increased brightness and has an ambient light sensor which dims the backlight automatically when required. In addition, Chip Monolithic Ceramic Capacitors are used throughout the unit for improved stability and durability especially in extreme temperature conditions and perform excellent in harsh industrial environments.
5-Wire Resistive Touch-Screen Panel
This rugged heavy-duty 7-inch touchscreen monitor is a versatile small form factor display product that incorporates the innovation of HDMI video 7-inch touchscreen models along with a 5-wire resistive Touch-Screen panel. Use this convenient touch-screen as your input device, control your mouse cursor or the mini onscreen keyboard that comes with your operating system. This display utilizes the USB port as an interface. You can connect several 700TSH touchscreen monitors to your computer and the touchscreens would work simultaneously through the multi-monitor support.
Connectivity
| External Ports | USB Type-C |
General
| AC Input Power | Not Available |
Electrical
| AC/DC Power Adapter | PA-130 / 12 VDC (Not Included) |
Environmental
| Storage Temperature | -30°C to 80°C |
| Operating Temperature | -4 to 158-degree F (-20 to 70-degree C) |
Physical
| Weight | 1.54 lb |
| Wall Mounting | Not Available |
Display
| Resolution | 1920 x 1080 |
| Brightness | 600 cd/m² |
| TV Screen Size (Diagonal) | 7" |
| Variable Frame Rates | Not Available |
| Touch Screen | 42190 |
| Panel Type | LCD |
| Viewing Angle (H x V) | 150 x 145° |
| Contrast Ratio | 700:1 |
| Dot Pitch | 1,843,200 (dots) |
Xenarc Technologies 7-Inch Touchscreen LCD Monitor with HDMI, DVI, VGA and AV Inputs
| Screen size | 7 inch, diagonal (16:9) |
| Physical resolution | 1024 (H) x 600 (V), WVGA |
| Supported PC resolution | 640 x 480 to 1920 x 1080 |
| Supported HDMI video signal | 480i, 480p, 720i, 720p, 1080i, 1080p |
| Dot resolution | 3072 x 600 = 1,843,200 (dots) |
| Brightness | 600 cd/m² |
| Contrast ratio | 700:1 |
| Viewing angle | 150 degree horizontal, 145 degree vertical |
| Response time (Tr/Tf) | 10/15ms (typical) |
| Touch screen interface | USB port |
| Operating voltage range | DC 10V to 35V |
| Power supply | DC 12V |
| Power consumption | <10W |
| Operating temperature | -4 to158-degree-F (-20 to 70-degree-C) |
| Storage temperature | -22 to 176-degree-F (-30 to 80-degree-C) |
| MTBF (Mean Time Between Failures) | >55,000 hours or >6.2 years of continuous operation |
| Dimensions (W x H x D) | 196 x 121.5 x 35 mm |
| Weight | 1.54 lb |
