Xenarc Technologies extended the versatility of its iconic 700 series line of small form factor mini portable 7-inch monitor displays with the introduction of a Sunlight Readable 7-inch LCD touchscreen with HDMI video input and capacitive touchscreen that now incorporates an optically bonded touch and LCD panel, that offers IK08 impact protection. The heavy-duty rugged display monitor uses the latest 7-inch LCD panel with a 1024x600 native resolution while incorporating an LED backlight technology for a brightness rating of 1,000NIT and an ambient light sensor which dims the backlight automatically when required. The high brightness of this 7-inch display HDMI monitor makes it ideal for outdoor applications under direct sunlight as well as any other applications where a bright, non-reflective display may be effective.
Sunlight Readability
This latest product in the 7-inch touchscreen monitor line offers superior readability under direct sunlight. Sunlight readability is further enhanced by its touchscreen optical bonding and advanced anti-reflective coating. Air gap is eliminated between the touchscreen panel and the LCD panel to increase clarity, contrast, and durability. In addition, chip monolithic ceramic capacitors are used throughout the 7-inch HDMI display unit for improved stability and durability especially in extreme temperature conditions.
Capacitive Touchscreen Panel
This versatile 7-inch HDMI, VGA, DVI monitor incorporates a capacitive touchscreen panel. Capacitive sensing provides a more responsive touch interface than resistive touch. It achieves this by using the capacitance of human skin to detect the proximity or position of the input. Proximity sensing allows the touch interface to work even if protective glass or coating is used over the display. Use the convenient touch-screen as your input device, control your mouse cursor or the mini on screen keyboard that comes with your operating system. The 7-inch HDMI touch screen utilizes the USB port as the interface. You can connect several 702GSH HDMI monitors to your computer and the touchscreens would work simultaneously through the multi-monitor support.
Connectivity
| External Ports | USB Type-C |
General
| AC Input Power | 12 VDC |
Environmental
| Storage Temperature | -30°C to 80°C |
| Operating Temperature | -4 to 158-degree-F (-20 to 70-degree-C) |
Physical
| Weight | 1.54 lb |
| Wall Mounting | Not Available |
Display
| Resolution | 1920 x 1080 |
| Brightness | 1000 cd/m² |
| TV Screen Size (Diagonal) | 7" |
| Variable Frame Rates | Not Available |
| Touch Screen | 42190 |
| Panel Type | LCD |
| Viewing Angle (H x V) | 150 x 145° |
| Contrast Ratio | 700:1 |
| Dot Pitch | 1,843,200 (dots) |
Xenarc Technologies 7-Inch IK08 Rugged Sunlight Readable Optically Bonded Touchscreen LCD Monitor
| Screen size | 7 inch, diagonal (16:9) |
| Physical resolution | 1024 (H) x 600 (V), WVGA |
| Supported PC resolution | 640 x 480 to 1920 x 1080 |
| Supported HDMI video signal | 480i, 480p, 720i, 720p, 1080i, 1080p |
| Dot resolution | 3072 x 600 = 1,843,200 (dots) |
| Brightness | 1,000 cd/m² |
| Contrast ratio | 700:1 |
| Viewing angle | 150 degree horizontal, 145 degree vertical |
| Response time (Tr/Tf) | 10/15ms (typical) |
| Touch screen interface | USB port |
| Operating voltage range | 10 to 35 VDC |
| Power supply | 12 VDC |
| Power consumption | <10W |
| Operating temperature | -4 to 158-degree-F (-20 to 70-degree-C) |
| Storage temperature | -22 to 176-degree-F (-30 to 80-degree-C) |
| Impact protection rating | IK08 |
| MTBF (Mean Time Between Failures) | >55,000 hours or >6.2 years of continuous operation |
| Dimensions (W x H x D) | 196 x 121.5 x 35 mm |
| Weight | 1.54 lb |
