In a follow-up of the 800 series and the 805 series, Xenarc Technologies added to its 8-inch line of off-the-shelf touch screen displays solutions with the introduction of an 8-inch LCD touchscreen display monitor with a brightness rating of 1,000NIT while boasting a 5-wire GFG Armored Resistive touch panel. The high brightness of this 8-inch touchscreen display, as well as the GFG armored touch panel and ruggedized aluminum casing, makes it ideal for industrial or outdoor applications.
Rugged and Versatile
This rugged and versatile 8-inch touchscreen display offers superior readability under direct sunlight and is perfect for outdoor applications. With proprietary technology, Xenarc was able to increase the brightness rating to 1,000NIT, and the contrast ratio to 500:1. The sunlight readability of this 8-inch display touchscreen is further enhanced by its advanced anti-reflective coating.
GFG Armored
The 8-inch Glass-Film-Glass (GFG) armored touch panel has a surface hardness of 7H, significantly higher than the standard 3H of an ITO film on regular resistive touch panels. This new technology employs a 0.2mm thin glass on top of the resistive touch screen. This layer features anti-scratch properties, and is not only resistant to abrasion, but also chemicals which makes this 8-inch touch displays relevant to a number of rugged applications including Industrial, Medical, Food and Hospitality, Gas stations or Chemical plants, Marine, Transportation, and Air Transportation operating systems, etc.
Anti-Reflective Anti-Fingerprint Coatings
The GFG panels also come with anti-reflective and anti-fingerprint coatings, further enhancing the high bright panel within the display. All of these enhancements result in an 8-inch rugged display LCD LED monitors that are corrosion, scratch, and high temperature resistant, and easy to clean.
Convenient Input Device
Use the convenient 8-inch touch-screen as your input device, control your mouse cursor, or the mini on-screen keyboard that comes with your operating system. The 8-inch touch screen utilizes the USB port as the interface. You can connect several of our 8-inch touchscreen displays to your computer and the 8-inch touchscreens would work simultaneously through the multi-monitor support.
Anodized Aluminum Faceplate
The brushed, anodized aluminum faceplate gives the 8-inch inch display LCD touchscreen monitor a modern yet elegant look. The entire enclosure is constructed with aluminum, making the unit strong and ruggedized.
High-Grade Display Components
By utilizing high-grade display and touchscreen components, this 8-inch LCD LED outdoor portable display advanced touchscreen monitor is perfect for industrial, in-car computing applications, or any other applications where a small, portable, and durable 8-inch touch screen display is required.
Connectivity
| External Ports | USB Type-C |
General
| AC Input Power | Not Available |
Electrical
| AC/DC Power Adapter | PA-130 / 12 VDC (Not Included) |
Environmental
| Storage Temperature | -30°C to 80°C |
| Operating Temperature | -4 to 158-degree F (-20 to 70-degree C) |
Physical
| Weight | 2.64 lb |
| Wall Mounting | Not Available |
Display
| Resolution | 800 x 600 |
| Brightness | 1000 cd/m² |
| TV Screen Size (Diagonal) | 8" |
| Variable Frame Rates | Not Available |
| Touch Screen | 42190 |
| Panel Type | LCD |
| Viewing Angle (H x V) | 140 x 120° |
| Contrast Ratio | 500:1 |
| Dot Pitch | 1,440,000 (dots) |
Xenarc Technologies 8-inch GFG Armored Touchscreen LCD Monitor with VGA HDMI DVI Inputs
| Screen size | Diagonal 8-inch (4:3) |
| Physical resolution | 800 (H) x 600 (V) SVGA |
| Supported resolution | 640 x 480 to 1600 x 1200 |
| Dot resolution | 2400 x 600 = 1,440,000 (dots) |
| LCD brightness | 1000 cd/m² |
| Contrast ratio | 500:1 |
| Viewing angle | 140-degree Horizontal, 120-degree Vertical |
| Response time (Tr/Tf) | 10/15ms (Typ.) |
| Touch screen interface | USB port |
| Operating voltage range | DC 9V to 36V |
| Power supply | DC 12V |
| Power consumption | < 14W |
| Operating temperature | -4 to 158-degree F (-20 to 70-degree C) |
| Storage temperature | -22 to 176-degree F (-30 to 80-degree C) |
| MTBF (Mean time between failures) | > 55,000 Hours or > 6.2 Years of continuous operation |
| Dimension (mm) | 228W x 164H x 36D |
| Weight | 2.64 lb |
